PVDF Plate Extrusion Line
Extruder: / /; Extruder Type: Single-screw, Hastelloy C-276 wetted / Single-screw, Hastelloy C-276 wetted / Single-screw, Hastelloy C-276 wetted; Screw Diameter: 45 mm / 65 mm / 90 mm; L/D Ratio: 30:1 / 30:1 / 30:1
Extruder: / /; Extruder Type: Single-screw, Hastelloy C-276 wetted / Single-screw, Hastelloy C-276 wetted / Single-screw, Hastelloy C-276 wetted; Screw Diameter: 45 mm / 65 mm / 90 mm; L/D Ratio: 30:1 / 30:1 / 30:1
Available Configurations: Model 80/156 (standard) / Model 92/188 (high capacity); Screw Configuration: Conical twin-screw, counter-rotating
Available Models: JWPE-150, JWPE-170, JWPE-180; Screw Diameter Options: 150 mm / 170 mm / 180 mm; Output Range (model dependent): 500 – 800 kg/h; Main Motor Power: 185-200 kW / 250-315 kW / 355-400 kW
Extruder Type: Single-screw (standard) or Twin-screw (option); Screw Diameter Options: 90 mm / 120 mm (single-screw); L/D Ratio: 33:1 (single-screw) / 40:1 (twin-screw); Screw Material: 38CrMoAlA nitrided steel (single) / W6Mo5Cr4V2 (twin)
Extruder Type: Single-screw, large-diameter low-speed design; Screw Diameter Options: 120 mm / 130 mm / 150 mm; Screw Material: 38CrMoAlA nitrided steel; Nitrided Layer Depth: 0.5-0.7 mm
Extruder Type: Single-screw, large-diameter low-speed design; Screw Diameter Options: 120 mm / 130 mm; Screw Material: 38CrMoAlA nitrided steel; Nitrided Layer Depth: 0.5-0.7 mm
Production Capacity: 500 kg/h / 700 kg/h / 800 kg/h; Screw Diameter: Φ120 mm / Φ150 mm / Φ180 mm; L/D Ratio: 38:1 / 38:1 / 38:1; Screw Design: Barrier screw with mixing section / Barrier screw with mixing section / Barrier screw with mixing section
Jwell Machinery Co., Ltd sets up in 1997 , we are large manufacturer of plastic extrusion machinery in China, our headoffice was located in Shanghai.
